Transformer Oil Purifier

FUOOTECH 3000LPH ZY-50 Series Single-stage Vacuum Transformer Oil Filtration Equipment

Product ID：{dede:field name='typename'/}
QQ：1227182945
Phone: WA +86 18984259103
Tel: WA +86 18984259103
Email: sales05@fuootech.com
Time: 2025-08-27 16:22:25

Product Description

ZY Series Single-stage Vacuum Transformer Oil Filtration Equipment

FUOOTECH® is one of the biggest vacuum transformer oil purifier factory in China with over 19 years development and producing experience. Manufactured by FUOOTECH®, ZY Series Single-stage Vacuum Transformer Oil Filtration Equipment is mainly used to extend the lifetime of all types of insulating oils used in transformer, circuit breaker, mutual inductor, voltage regulators, capacitor, high-voltage switch, switchgear, etc. or to fill and transfer the insulating oil into the transformers, as well as storage tank to tank, tank to transformer.

After completion of dehydration, degassing and fine filtration process, the dissolved water, liquid water, trace water, dissolved gases, particles and tiny impurities can be removed completely to upgrade the properties of transformer insulating oil.

transformer oil purifier.jpg

ZY (4).jpg

Detailed Photos

Features

1. Duplex-Stereo 3D film evaporation technology, combined with unique & advanced dehydration and degassing elements, can rapidly and effectively separate water, gas from oil.

2. Multi-stage precision filtration system, stainless steel filters’ filtration combined with molecular adsorption technologies, remove different sizes of impurities and particles thoroughly.

3. Efficient High density electrical heating system adopts special indirect heating method, heating uniformity, less power consumption, safe, and reliable.

4. Double-safety liquid level controlling system and pressure protective system ensure the machine operation easy and safely.

5. Adopts interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak.

6. Fully automatic temperature controlling system, digital type temperature gauge and temperature sensor, monitoring and controlling oil’s actual heating condition and temperature.

7. Small volume, light weight, easily movable, low maintenance cost and time.

Technical Parameters

Parameters	Unit	ZY-10	ZY-20	ZY-30	ZY-50	ZY-100	ZY-150	ZY-200	ZY-300
Flow rate	L/H	600	1200	1800	3000	6000	9000	12000	18000
Working vacuum	MPa	-0.06 ～ -0.095
Working pressure	MPa	≤0.4				≤0.5
Working without Trouble	H	≥4000
Continuous Working	H	≥150
Temperature range	℃	20 ～ 80
Power supply		380V, 3 phase, 50 Hz (or as per your requirements)
Working noise	dB(A)	≤ 80
Heating power	KW	12	13	15	30	48	60	72	90
Total power	KW	13.5	14.5	16.5	33.5	53	65	76	98
Inlet/outlet caliber	mm	φ25	φ25	φ25	φ32	φ42	φ50	Φ60	φ65
Weight	Kg	230	250	280	300	550	700	950	1200
Size	mm	950× 650× 1050	1100× 700× 1350	1150× 850× 1450	1200× 950× 1580	1600× 1000× 1800	1650× 1100× 1850	1800× 1200× 1900	1900× 1200× 2000
After Filtration (Performance)		Moisture (Water Content)				≤ 8 PPM
		Gas Content				≤0.1% (Vol)
		Impurities Degree (Filtration precision)				≤ 5 micron
		Breakdown Voltage (Dielectric)				≥60 ~ 68 KV
		Cleanliness				≤NAS 1638 Grade 6
